TQC CUREVIEW GRADIENT OVEN

$0.00

The CureView Gradient Oven is a flexible oven that allows the user to heat up test panels on a glass bed to a variety of temperature profiles.

Description

The CureView Gradient Oven is a flexible oven that allows the user to heat up test panels on a glass bed to a variety of temperature profiles, varying from ambient +5˚C to 350˚C / ambient +41˚F to 662˚F. Elevated temperatures are instantly generated by 32 spectral filtered IR halogen heaters, which can be controlled individually and allow the setting of any form of temperature gradient, varying from a parabolic shaped gradient, an ascending or descending slope or a number of temperature blocks.The CureView Gradient Oven allows importing of gradient profiles, measured by the TQC CurveX oven logger system in order to simulate the production process on laboratory scale.

Item No: AB8000 CureView Gradient Oven 230/110 VAC

Categories:

Standards: ISO 2812-5

https://www.tqc.eu/wp-content/uploads/2017/08/Instruction-Manual-Cureview.pdf

https://www.tqc.eu/wp-content/uploads/2017/08/Datasheet-CureView.pdf

https://www.tqc.eu/wp-content/uploads/2017/08/cureview-gradient-oven-ab8000-lf44.pdf

https://www.tqc.eu/wp-content/uploads/2017/08/leaflet-cureview-gradient-oven-ab8000.pdf
